Contour measuring gauge for determining the average inside diameter of round, oval polygonal bores,
with scaled ring and vernier. Tape width, 20mm
- Easy and fast measurement of the medium inside diameter of hollow parts, also in flexible workpieces, with Ø 14-330 mm.
- Measuring depth between 15 and 50 mm.
- Actual diameter is read at the scale ring and the vernier scale.
- Digital Novometer: with resolution 0.01mm is also available.
19.30mm – 24.00mm, 24.01mm – 26.00mm, 26.01mm – 29.00mm, 29.01mm – 32.00mm, 32.01mm – 35.00mm, 35.01mm – 38.00mm, 38.01mm – 41.00mm, 41.01mm – 45.00mm, 45.01mm – 48.00mm, 48.01mm – 51.00mm, 51.01mm – 58.00mm, 58.01mm – 65.00mm, 65.01mm – 70.00mm, 70.01mm – 80.00mm, 80.01mm – 90.00mm, 90.01mm – 100.00mm, 100.01mm – 115.00mm, 115.01mm – 130.00mm, 130.01mm – 145.00mm, 145.01mm – 165.00mm, 0.20mm – 0.50mm, 0.51mm – 1.00mm, 1.01mm – 2.00mm, 2.01mm – 4.50mm, 4.51mm – 7.00mm, 7.01mm – 10.00mm, 10.01mm – 13.00mm, 13.01mm – 16.00mm, 16.01mm – 19.45mm
